Camera Specifications |
|
Sensor type | 1/2.9" progressive scan CMOS sensor |
Lux Level(illumination) | Color: 0.02Lux@ (F2.0, ACG ON), B/W: 0Lux with IR |
Shutter speed | Auto/Manual, 1s to 1/100,000s |
AGC | Yes |
Lens | 2.8MM fixed focus |
IR distance | IR up to 30 Meter |
IR function | Smart IR, ICR Dual Filter, IR LED power adjustable |
Compression/Video/Audio |
|
Video compression | H.265+, H.265, H.264+, H.264, MJPEG |
H.264/H.264+ Profile | Main, High, Baseline |
Main stream | 2MP 1920x1080/1MP 1280x720/D1/VGA |
Second stream | 704x576(D1), 704x288(2CIF), 352x288(CIF), 640x360 |
Record & Live frame rate | Selectable 1 ~ 25 fps at 4MP, 3MP, 2MP, 1.3MP, 1MP at on Main, Second stream @ 15fps |
Bitrate control | 32Kbps ~ 6Mbps, VBR, CBR, I-Frame interval |
Video Analysis |
|
Intelligent video analysis | Tripwire, Perimeter |
Intelligent alarm | Motion Detection, Mask Alarm, IP Address Conflict |
Intelligent codec | 256kbps for 1080P video stream, 1GB storage for 24 hours recording |
Intelligent image | Advanced algorithm, Identifies persons clearly |
Camera Functions |
|
WDR | Digital WDR |
Day/Night | Auto(Outside/Inside), Color, B/W |
Digital noise reduction | 3DNR (Close/Ordinary/Expert) |
Light compensation | BLC Off/On, 1 area, Customize design, HLC Off/On adjustable |
White balance | Auto/Manual/Lock/Nature/Sunshine/Day Light/Warm light |
Other functions | Smart defog control, EIS(Image Stabilizer), Flip control, Motion detection, Privacy masking |
Image control | Brightness, Contrast, Sharpness, Saturation |
OSD display | 16x16, 32x32, 48x48, adaptable size, Letters Such as Week, Date, Time, Total 3 Regions |
Alarm alert | On-screen alerts/Link out/FTP upload, PTZ trigger/E-MAIL/Pre-Post record(through NVR) |
Network, Storage, Interface |
|
Protocol | TCP/IP, HTTP, FTP, DHCP, DNS, DDNS, MULTICAST, IPV4, NTP, UDP, Telnet |
Pre & Post recording | Pre : 5 to 15sec, Post : 10 to 60 sec |
Network storage | FTP(pre & post upload) |
LAN port | 1x Port RJ-45, 10M/100M ethernet |
Storage | Built-in MicroSD card slot, up to 512 GB, |
Audio in | Built-in Mic |
Software Support |
|
Onvif | Yes, Profile S |
CMS software | iCRYS series, up to 256CH(IP+NVR+Matrix) |
3rd Party VMS/NVR /CMS | Onvif/SDK |
Mobile | Cloud support Android /iOS through NVR |
User login | 8 User / 4 level of rights, Simultaneous login ≤7 user client |
Snap shot management | Schedule, Link with FTP or Email |
Encryption | Off/AES |
General |
|
Power supply | DC 12V ±15% & PoE (802.3af) |
Power consumption | <3W @ IR Off, <6W @ IR ON |
Voltage protection | TVS 6000V, Lightning/Surge 2000V(power) 1000V(RJ45) |
IP & Vandal protection | IP67 |
Reset switch | Yes |
Operating temp. & humidity | -35°C ~ 65°C & 0% ~ 95% RH |
Enclosure | 3 Axis rotation dome, Metal + Plastic dome |
Weight (g) & Dimension | <0.4KG camera, Ø 116.6 mm(D) X 83.7mm(H) |
