Camera Specification

Sensor type

1/2.9" progressive scan CMOS sensor

Lux Level(illumination)

Color 0.05 Lux, B/W 0.01Lux @(F1.2, AGC ON), 0Lux @ IR On

Shutter speed

Auto/Manual, 1/2s ~ 1/100,000s

AGC

Yes

Lens

N.A

Focus control

N.A

ICR

N.A

IR wave length

N.A

IR distance

IR up to 50 Meter

IR function

Smart IR, ICR Dual Filter, IR LED power adjustable

Compression/Video/Audio

Video compression

H.265+, H.265, H.264+, H.264, MJPEG

Video resolution

N.A

H.264/H.264+ Profile

Main, High, Baseline

Main stream

2MP 1920x1080/1.3MP 1280x960/ 1MP 1280x720

Second stream

704x576(D1), 704x288(2CIF), 352x288(CIF), 640x360

Third stream

N.A

Record & Live frame rate

Selectable 1 ~ 25fps at 2MP, 1.3MP, 1MP at on Main, Second stream @ 15fps

Bitrate control

32Kbps ~ 6Mbps, VBR, CBR, I-Frame interval

Bit Rate

N.A

Audio compression & bitrate

N.A

Smart Functions

Intelligent alarm

Advanced motion detection, Recognize only persons from all the moving objects

Intelligent codec

256kbps for 1080P video stream, 1GB storage for 24 hours recording

Intelligent image

Advanced algorithm, Identifies persons clearly

Camera Functions

WDR

100dB, Auto/Manual adjustable

Day/Night

Auto(Outside/Inside), Color, B/W

Digital noise reduction

3DNR (Close/Ordinary/Expert)

Light compensation

BLC Off/On, 1 area, Customize design, HLC Off/On adjustable

White balance

Auto/Manual/Lock/Nature/Sunshine/Day Light/Warm light

Other functions

Smart defog control, EIS(Image Stabilizer), Flip control, Motion detection, Privacy masking

Image control

Brightness, Contrast, Sharpness, Saturation

OSD display

16×16,32×32,24×24,48×48,64×64 character size 5 area arrangement @ Time/Date/Week/Character/PTZ angle

Alarm alert

On-screen alerts/Link out/FTP upload, PTZ trigger/E-MAIL/Pre-Post record(through NVR)

Network, Storage, Interface

Protocol

TCP/UDP/HTTP/802.1x/FTP/UPnP/Multicast/DNS/DDNS/NTP/RTSP/DHCP/PPPoE

Pre & Post recording

Pre : 5 to 15sec, Post : 10 to 60 sec

Storage function

N.A

Network storage

FTP(pre & post upload)

LAN port

1x Port RJ-45, 10M/100M ethernet

Storage

N.A

Two-Way Intercom

N.A

Audio

N.A

Alarm

N.A

Video output

N.A

USB

N.A

Other ports

N.A

Software Support

Onvif

Yes, Profile S

CMS software

iCRYS series, up to 256CH(IP+NVR+Matrix)

3rd Party VMS/NVR /CMS

Onvif/SDK

Mobile

Cloud support Android /iOS through NVR

User login

8 User / 4 level of rights, Simultaneous login ≤7 user client

Snap shot management

Schedule, Link with FTP or Email

Encryption

Off/AES

General

Power supply

DC 12V ±15% & PoE (802.3af)

Power consumption

<3W @ IR Off, <7W @ IR ON

Voltage protection

TVS 6000V, Lightning/Surge 2000V(power) 1000V(RJ45)

IP & Vandal protection

IP67

Reset switch

N.A

Operating temp. & humidity

-30°C ~ 60°C & 0% ~ 95% RH

Enclosure

Built-in 3 axis bracket, Metal+Plastic housing

Weight (g) & Dimension

<0.5Kg camera, 210mm(L) X 82mm(W) X 83mm(H)
