Camera Specification

Sensor type

1/2.8" progressive scan CMOS sensor

Lux Level(illumination)

Color: 0.002Lux@ (F1.6, ACG ON), B/W: 0Lux with IR

Shutter speed

Auto/Manual, 1s ~ 1/100,000s

AGC

Yes

Lens

4.0MM fixed focus

Focus control

N.A

ICR

Mech. ICR

IR wave length

N.A

IR distance

up to 50 Meter

IR function

Smart IR, ICR Dual Filter, IR LED power adjustable

Compression/Video/Audio

Video compression

H.265+, H.265, H.264+, H.264, MJPEG

Video resolution

Main, High, Baseline

H.264/H.264+ Profile

N.A

Main stream

4MP(2560x1440P)/3MP(2304x1296P)/2MP(1920x1080P)/1.3MP(1280x960P)/1MP(1280x720P)

Second stream

704x576(D1), 704x288(2CIF), 352x288(CIF), 640x360

Third stream

N.A

Record & Live frame rate

25fps at 4MP/3MP/2MP/1.3MP/1MP, 15fps at second stream

Bitrate control

32Kbps ~ 6Mbps, VBR, CBR, I-Frame interval

Bit Rate

N.A

Audio compression & bitrate

N.A

Video Analysis

Intelligent video analysis

Tripwire, Perimeter

Perimeter detection mode

N.A

Intelligent alarm

Advanced motion detection, Recognize only persons from all the moving objects

Alarm & IVA trigger

N.A

Corridor control

N.A

Region of Interest(ROI)

N.A

Advanced warning

N.A

Camera Functions

WDR

120dB, Auto/Manual adjustable

Day/Night

Auto(Outside/Inside), Color, B/W

Digital noise reduction

3DNR (Close/Ordinary/Expert)

Light compensation

BLC Off/On, 1 area, Customize design, HLC Off/On adjustable

White balance

Auto/Manual/Lock/Nature/Sunshine/Day Light/Warm light

Other functions

Smart defog control, EIS(Image Stabilizer), Flip control, Motion detection, Privacy masking

Image control

Brightness, Contrast, Sharpness, Saturation

OSD display

16x16, 32x32, 48x48, 64x64, adaptable size, Letters Such as Week, Date, Time, Total 3 Regions

Alarm alert

On-screen alerts/Link out/FTP upload, PTZ trigger/E-MAIL/Pre-Post record(through NVR)

Network, Storage, Interface

Protocol

TCP/IP, HTTP, FTP, DHCP, DNS, DDNS, MULTICAST, IPV4, NTP, UDP, Telnet

Pre & Post recording

Pre : 5 to 15sec, Post : 10 to 60 sec

Storage function

N.A

Network storage

FTP(pre & post upload)

LAN port

1x Port RJ-45, 10M/100M ethernet

Storage

Built-in MicroSD card slot, up to 512 GB

Two-Way Intercom

N.A

Audio

Built-in Mic

Alarm

N.A

Video output

N.A

USB

N.A

Other ports

N.A

Software Support

Onvif

Yes, Profile S

CMS software

iCRYS series, up to 256CH(IP+NVR+Matrix)

3rd Party VMS/NVR /CMS

Onvif/SDK

Mobile

Cloud support Android /iOS through NVR

User login

8 User / 4 level of rights, Simultaneous login ≤7 user client

Snap shot management

Schedule, Link with FTP or Email

Encryption

Off/AES

General

Power supply

DC 12V ±15% & PoE (802.3af)

Power consumption

<3W @ IR Off, <7W @ IR ON

Voltage protection

TVS 6000V, Lightning/Surge 2000V(power) 1000V(RJ45)

IP & Vandal protection

IP67

Reset switch

Yes

Operating temp. & humidity

-35°C ~ 65°C & 0% ~ 95% RH

Enclosure

Built-in 3 axis bracket, Metal+Plastic housing

Weight (g) & Dimension

<0.4Kg camera, 160.8mm(L) X 68mm(W) X 74.5mm(H)
