ystem

Video compression

H.265+/H.265/H.264HP/H.264MP/H.264BP

Audio compression

ADPCM/G.711A/G.711U

Operation system

Embedded Linux

Signal system

Auto detect

Bandwidth throughput

620Mbps(Incoming/Outgoing 320Mbps)

Remote connections

160Channels

Record/Playback/Streaming

IPC input

40CH @ 4K/6MP/5MP/4MP/3MP/2MP/720P/4CIF

Live Screen window

40CH/36CH/25CH/20CH/16CH/10CH/9CH/8CH/6CH/4CH/1CH

Live resolution

4CH@4K/6MP, 5CH@5MP, 8CH@4MP/3MP, 16CH@1080P, 32CH@720P, 64CH@4CIF Realtime Display

Record resolution

16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Record frame rate

Mainstream 25fps(P)/30fps(N), Sub stream 25fps(P)/30fps(N)

Record function

Smart Record, Records Encryption, Records TAG, One Key Start Recording, Trigger Recording

Smart record

Different recording bitrate at different time zone, i-Frame recording only record key frame to lower frame rate

Trigger record

Manual/Timing/Motion Detection/Port Alarm/ IVA Alarm/Video Occlusion

Playback channel

16CH @1080P/720P/D1, 8CH @4MP/3MP, 4CH @4K/6MP/5MP

Smart search

YES, Quickly search target iVA videos , Only for iCRYS series cameras

Playback function

Play, Pause, Stop, Rewind, Fast, Slow, Next & Previous File/Camera, Full screen, Repeat, Shuffle, Backup selection, Digital Zoom

Instant Access Function

Quick playback up to last 5min, Quick backup

Record quality

Best/Better/Good/Normal/Worst

Record stream Bitrate

VBR/CBR (32 ~ 16384Kb/s)

Sub stream

D1/CIF/QCIF, Frame rate selectable

Pre & Post alarm record

Pre : 10 ~ 600 sec, Post : 5 ~ 60sec

Array & Storage

Array method

-

Raid management

-

Redundant recording

-

Hot backup disk

-

Hot Swap

-

Hot standby

N + M

Hard disk interface

2HDD (SATA Port)

Hard disk capacity

Max. up to 10TBEach Port

E-SATA interface

-

Management Function

HDD Grouping and Quota, SMART HDD Check, Record file TAG, File lock

ANR

Download Stored Video Automatically from Camera SD Card, When NVR Online

Intelligent Analytics Functions

Video Analytics

1~2CH @ Any H.264 Onvif IP Camera(2MP)(Tripwire, Perimeter, Object Detection & Count) and 1Ch ~ 40Ch with iCRYS iVA Process Camera(Facial detection/Fast voving/ Missing & Foreign object/Crowd & Screaming detection /Tripwire/Perimeter/People counting/Loitering/Parking/Blurred image/Audio offline/Off-Position)

Video diagnosis

Video color cast detection, Noise Detection, Electromagnetic interference testing, Fuzzy video Detection

Motion detection

-

Motion detection

-

HDD alarm trigger

Disk Full, No Disk, Disk R/W Error, Redundancy Error

Intelligent alarm

-

Event & Alarm trigger

E-MAIL, Snap, NVR Sound Buzzer, OSD, Alarm Server Devices, Video Recording, Alarm Out, PTZ Trigger

Network alarm trigger

illegal Access, IP Address Conflict, Network Lost, MAC Conflict

Icrys Series camera Function

Corridor Control, Plug & Play, Image Flip, one key control,

Private functions

-

Alarm trigger

Local Alarm Port Out, NVR Sound Buzzer, OSD, Alarm Server Devices

Video/Audio/Interface

Network

2x RJ45 Port 10/100/1000MBPS Auto detection(Load Balance, Redundant, Dual IP)

HDMI output

3840×2160,2560×1600, 1920x1080,1280x720, 1280x800,1366x768,800x600,1024x768,1440x900 Adjustable Output, Self-detection

VGA output

1920x1080,1280x720,1280x800,1366x768, 800x600,1024x768,1440x900 Adjustable Output, Self-detection

Alarm

16Ch inputs, 4Ch outputs, 3P Connector, 0V Signal

Audio

1Ch input, 3.5mm Jack( Intercom), 1Ch output

Communication Protocol

2x RS485, 1x RS232

USB

3 Port (1 X USB 3.0, 2 X USB2.0)

Network protocol

TCP/UDP/MULTICAST/UPNP/HTTP/DHCP/PPPoE/DDNS/NTP/ HTTPS/NFS/FTP/RTSP/SMTP/HTTPS/SADP, Alarm Server, Auto Search iCRYS Series IP Camera

Backup

-

FTP & E-Mail alert

-

Key functions

-

Snap shot

Schedule, Link with FTP or Email

Backup

-

OSD Setups

Channel Wise Color/Position/Transparency/Text/Masking/Date & Time Format

Log generation

Channel, Event based, Date and Time selection, Export

Software Supports

Onvif compliant

Yes, Profile S

Key function

One key record, One key intercom, Digital zooming

P2P cloud

I-Phone, IPAD, Android, Record, Playback, Push Notification, Device controls

Web browser

IE, Safari, Chrome, Edge

Other functions

E-MAIL Alert, FTP upload

General

Power supply

100 ~ 240V AC, 50 ~ 60Hz

Power consumption

<26W without HDD

Language

English, Spanish, French, German, Chinese & Many More

Operation conditions

-10 ℃ ~ +55 ℃ (+14 F~ + 131 F), 10% ~ 90% RH

Enclosure

1U, Black color, Metal case

Weight (g) & Dimension

<2.5Kg, 345(D) x 275(W) x 48mm(H)
