Image Sensor :
1/2.8” CMOS
Signal System : PAL/NTSC
Min Illumination : Color: 0.02Lux@ (F2.0, ACG ON), B/W: 0Lux with IR
Shutter Time :
1s to 1/100,000s
Day & Night:
Dual IR Cut Filter with Auto Switch
Wide Dynamic Range : Digital WDR
Angle Adjustment : Bracket, pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°

Lens Type :
Fixed
Focus :
4mm
Lens Mount :
M12
Aperture :
F2.0, Fixed
FOV :
Horizontal field of view: 83.3°(4mm) 46.8°(4mm)

IR LEDS : 2
IR Range : Up to 50m
Wavelength : 850nm

Video Compression :
IH+265/H.265/H.264
Video Bit Rate : 32Kbps~6Mbps
Audio Compression : G.711/G.711U/ADPCM
Audio Bit Rate :
8K~48Kbps

Max. Resolution : 1920×1080
Main Stream :
PAL: 25fps (1920×1080, 1280×720, 704×576, 640×480)
NTSC: 30fps (1920×1080, 1280×720, 704×480, 640×480)
Sub Stream :
PAL: 25fps (704×576, 704×288, 640×360, 352×288)
NTSC: 30fps (704×480, 704×240, 640×360, 352×240)
Image Setting : Saturation, brightness, contrast, sharpness, adjustable by client software or web browser
Image Enhancement : BLC/3D DNR/HLC
OSD :
16×16, 32×32, 48×48, adaptable size, Letters Such as Week, Date, Time, Total 3 Regions
Privacy Mask :
Yes, 4 regions
Smart Defog :
Yes

Alarm Trigger :
Motion Detection, Mask Alarm, IP Address Conflict
Video Analytics : Tripwire, Perimeter

Protocols :
TCP/IP, HTTP, FTP, DHCP, DNS, DDNS, MULTICAST, IPV4, NTP, UDP, Telnet, ICMP, RTP, RTSP, UPnP
System Compatibility : ONVIF (PROFILE S/T/G), SDK
Remote Connection : ≤7
Client :
IH-VIEW
Web Version :
Web5

Communication interface : 1 RJ45 10M/ 100M self adaptive Ethernet port
Audio I/O :
Mic in

Web Client Language : English
Operating Conditions : -30°C~60°C, 0~95% RH
Power Supply:
DC 12V±25%, PoE (802.3af)
Power Consumption : MAX: 6W(12V) MAX: 8W(POE)
Protection :
IP67, Lightning protection, surge protection
Dimensions : 208×81×81mm(8.19×3.19×3.19inch)
Weight :
0.35Kg (0.a77lb)
