Weight	0.300 kg
Dimensions	11.7 × 11.7 × 9.6 cm
Camera	Image Sensor : 1/2.8” CMOS Signal System : PAL/NTSC Min Illumination : Color: 0.02Lux@ (F2.0, ACG ON), B/W: 0Lux with IR Shutter Time : 1s to 1/100,000s Day & Night: Dual IR Cut Filter with Auto Switch Wide Dynamic Range : Digital WDR Angle Adjustment : Bracket Pan 0~340°, tilt 0~75°, roate 0~360°
Lens	Lens Type : Fixed Focus : 2.8mm Lens Mount : M12 Aperture : F2.0, Fixed FOV : Horizontal field of view: 99.7°; Vertical field of view: 55.1°
ILLUMINATOR	IR LEDS : 1 IR Range : Up to 30m Wavelength : 850nm
COMPRESSION STANDARD	Video Compression : IH+265/H.265/H.264 Video Bit Rate : 32Kbps~6Mbps Audio Compression : G.711/G.711U/ADPCM Audio Bit Rate : 8K~48Kbps
IMAGE	Max. Resolution : 1920×1080 Main Stream : PAL: 25fps (1920×1080, 1280×720, 704×576, 640×480) NTSC: 30fps (1920×1080,1280×720, 704×480, 640×480) Sub Stream : PAL: 25fps (704×576, 704×288, 640×360, 352×288) NTSC: 30fps (704×480, 704×240, 640×360, 352×240) Image Setting : Saturation, brightness, contrast, sharpness, adjustable by client software or web browser Image Enhancement : BLC/3D DNR/HLC OSD : 16×16, 32×32, 48×48, adaptable size, Letters Such as Week, Date, Time, Total 3 Regions Privacy Mask : Yes, 4 regions Smart Defog : Yes
FEATURE	Alarm Trigger : Motion Detection, Mask Alarm, IP Address Conflict Video Analytics : Tripwire, Perimeter
NETWORK	Protocols : TCP/IP, HTTP, FTP, DHCP, DNS, DDNS, MULTICAST, IPV4, NTP, UDP, Telnet, ICMP, RTP, RTSP, UPnP System Compatibility : ONVIF (PROFILE S/T/G), SDK Remote Connection : ≤7 Client : IH-VIEW Web Version : Web5
INTERFACE	Communication interface : 1 RJ45 10M/ 100M self adaptive Ethernet port Audio I/O : Mic in
GENERAL	Web Client Language : English Operating Conditions : -30°C~60°C, 0~95% RH Power Supply: DC 12V±25%, PoE (802.3af) Power Consumption : MAX: 6W(12V) MAX: 8W(POE) Protection : IP66, Lightning protection, surge protection Dimensions : 117×117×96mm (4.61×4.61×3.78inch) Weight : 0.3Kg (0.66lb)
Warranty	Manufacturer
Country of Origin	India
